PROJECT
In 2011 :
MT. BAHARI JAYA LESTARI (BJL)
Principal Dimensions
Length Over All (LOA) : 49.07 M
Length Of Perpendicular : 44.26 M
Breadth (B) : 12.00 M
Depth (H) : 3.70 M
Draft (T) : 2.50 M
Class : Biro Klasifikasi Indonesia (BKI)
The first time sign in this company, first project that I deal with are 1 Unit MT. Bahari Jaya Lestari, owner by PT. Segara Laju Perkasa. This type tanker ship. Use 2 Main Engnies 430 BHP, rate out put 440 PS / 2170 min and use Gear Box marine type, gear ratio 5.15:1 Much information to be learned here, especially the hull construction is the initial step I need to understand. Overall material use carbon steel.
"MT. BAHARI JAYA LESTARI (BJL)"
PAN MARINE 12 & 14 (PM 12 & 14)
Principal Dimensions
Length Over All (LOA) : 35.10 M
Length Water Line (LWL) : 31.75 M
Length Of Perpendicular : 30.80 M
Breadth (B) : 7.00 M
Depth (H) : 3.40 M
Draft (T) : 1.35 M
Class : Bureau Veritas (BV)
The next project that I deal with are 2 Unit Crew Boat Ship Pan Marine 12 & 14, Owner by. PT. Pan Maritime Wira Pawitra. Each vessel using 3 Main Engines 1300 HP and 2 Auxiliary Engine 60 kVA. All boat construction is made of aluminum material.
"Pan Marine 12 (PM 12) at Workshop2"
"Pan Marine 12 (PM 12)"
"Pan Marine 14 (PM 14) at Workshop2"
"Pan Marine 14 (PM 14)"
In 2012 :
Wave Piercing Catamaran (WPC) Passenger Ferry QUICKSILVER IX
Principal Dimensions
Length Over All (LOA) : 42.00 M
Length Water Line (LWL) : 38.19 M
Breadth (B) : 15.60 M
Depth (H) : 4.55 M
Draft (T) : 1.40 M
Class : Lloyd's Register (LR)
The next project that I deal with are 1 Unit WPC. Catamaran Ship QUICKSILVER IX, Owner by PT. Caputra Mitra Sejati. Vessel using 4 Water Jet Kamewa 50A3, 4 Main Engines CAT C32 1081 kW, 4 Gear Box ZF3050 ratio 1.8:1 and 2 Auxiliary Engnies 125 kVA. All vessel construction is made of aluminum material. Perform calculations about Bill of Material and Bill Of Quantity.
"Front Right View Catamaran Quicksilver IX (QS IX)"
"Side View Catamaran Quicksilver IX (QS IX)"
"Front Left View Catamaran Quicksilver IX (QS IX)"
"Back View Catamaran Quicksilver IX (QS IX)"
In 2013 :
PAN MARINE 18 & 19 (PM 18 & 19)
Principal Dimensions
Length Over All (LOA) : 50.00 M
Length Water Line (LWL) : 43.50 M
Length Of Perpendicular : 41.96 M
Breadth (B) : 9.30 M
Depth (H) : 4.125 M
Draft (T) : 1.90 M
Class : American Bureau of Shipping (ABS)
The next project that I deal with are 2 Unit Crew Boat Ship Pan Marine 18 & 19, Owner by. PT. Pan Maritime Wira Pawitra. Each vessel using 3 Main Engines 6600/5500 BHP x 1800 rpm and Gear Box ZF 7600 A. All boat construction is made of aluminum material.
"Pan Marine 18 & 19 (PM 18& 19) at Workshop 1"
"Pan Marine 18 (PM 18)"
"Pan Marine 18 (PM 18)"
"Pan Marine 19 (PM 19)"
"Pan Marine 19 (PM 19)"
"Pan Marine 18 & 19 (PM 18 & 19)"
In 2014 :
Kapal Patroli Cepat 43M TNI ANGKATAN LAUT (KPC 43M TNI AL)
Principal Dimensions
Length Over All (LOA) : 44.00 M
Breadth (B) : 7.40 M
Depth (H) : 3.40 M
Draft (T) : 1.70 M
Class : Biro Klasifikasi Indonesia (BKI)
The next project that I deal with are 1 Unit Patrol Boat Ship KPC 43M, Owner by. TNI Angkatan Laut. Each vessel using 3 Main Engines MAN 1800 HP 2300 rpm. All boat construction is made of carbon steel material.
"Back View KPC 43M"
"Side View KPC 43M"
"Front Left View KPC 43M"
